Hand-held Temperature / Humidity Measuring Device for use with PT-100 Sensors.

Model: 5810-00

NIST Certification available.

Very exact temperature measuring device (+/-0.05C). Ideal as a reference device and for comparison measurements in service or as part of ISO9000 tasks High-precision hand-held device for PT100 temperature sensors. Suitable for measuring tasks requiring a high degree of precision. Mini USB port with software and online data collection. 25 languages available, is 0.05C across the full measuring range. Solely for use with PT100 sensors. Features on/off switch and touch screen. Comes with SmartGraph3 software.

See our sensors (PT100), which are not provided with this meter, or order the Kit (link below).

XP100 Kit: See our 5810-00 KIT which includes the XP100, 3120-52 Plunge Sensor and 2m cable

Purchase item

To read more information on this product, please Click Here.

Technical Data

Additional Equipment

• XP100	Model: 5810-00
  Dimensions	6 3/4 x 2 1/2 x 1 1/3", 170x62x34 mm
  Accuracy	±0.05°C across frull measuring range
  Weight	Approx. 7 1/4oz, 205g
  Storage conditions
  Permissible ambient temperature	-20...60°C
  Operating rel. humidity	<90%r.h. non-condensing
  Operating conditions
  Operating rel. humidity	<90%r.h. (20g/m3) non-condensing
  Admissible height above absolute altitude	4000m
  Power supply
  Power supply	4 Alkaline LR6 AA 1.5V / USB 5V
  Active power consumption	Approx. 400mW
  Battery life passive	Approx. 1 year
  Battery life active	min. 24 hours
  Sensor power supply	5.5V ± 10% DC, max. 200mA
  Data storage
  Integrated data storage	up to 200 gauges taking approx. 1 mill. values
  Interface
  USB	Cable and SmartGraph3 software included in delivery
  Display
  Definition of measured values	2 decimal places
  Display
  Control	Touch screen, capacitive
  Technology	TFT, resolution 240x320, 65k colors, very good contrast due to Piezoresistive technology
  Surface, toughened glass	Degree of hardness: 7, scratch-resistant

• Accessories
  5810-KIT: XP100 Temp Recording Meter with 3120-52 Plunge Sensor and 2m cable $855	5810-KIT
  PT100 plunge sensor, short	3120-520
  PT100 plunge sensor, long	3120-530
  PT100 plunge sensor, long	3120.540
  PT100 plunge sensor out of stainless steel for foodstuffs	3120-550
  Immersion probe for XP100	3120-560
  PT100 surface sensor	3120-600
  Extension cable for sensor, 10m	8120-KAB10
  Extension cable for sensor, 2m	8120-KAB2
